Basic Info.
Model NO.
uvc bulb sterilizer
Voltage
110/240V
Disinfection Method
Ultraviolet
Useage
UVC Bulb Sterilizer
Shell Material
Ss#304/316
Lamp Power
6-660W
Input Voltage
110V/240V 50/60Hz
Water Treatment Capability
0.5-144gpm
Water Capacity
421-33739cm³
Lamp Quantity
1-12PCS
Length
212-910mm
Usage
Water Treatment
Feature
Stainless Steel
Lamp Type
Single-End or Double-End
Samples
Accept
OEM
Accept
Transport Package
1set/Medinum Box, 6boxes/Carton
Specification
6-660W
Trademark
Neutral or OEM
Origin
Anhui, China
HS Code
8543709990
Production Capacity
500000/Month
Product Description
uv sterilizer, uvc bulb sterilizer, uvc sterilizer, uvc bulb sterilizer
Specification
| Model | SS 6W | SS 12W | SS 16W | SS 25W | SS 30W | SS 35W | SS 55W |
| Shell material (Stainless steel) | #304/316 | #304/316 | #304/316 | #304/316 | #304/316 | #304/316 | #304/316 |
| Lamp power | 6W | 12W | 16W | 25W | 30W | 35W | 55W |
| Input voltage | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz |
| UV lamp quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Water treatment capability | 0.5GPM (0.1m³/Hr) | 1GPM (0.2m³/Hr) | 2GPM (0.4m³/Hr) | 6GPM (1.4m³/Hr) | 8GPM (1.8m³/Hr) | 10GPM (2.3m³/Hr) | 12GPM (2.7m³/Hr) |
| Water capacity | 421cm³ | 502cm³ | 990cm³ | 1687cm³ | 2684cm³ | 2810cm³ | 2810cm³ |
| Max operating pressure | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) |
| Test pressure | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) |
| Model | SS 110W | SS 165W | SS 220W | SS 330W | SS 440W | SS 550W | SS 660W |
| Shell material (Stainless steel) | #304/316 | #304/316 | #304/316 | #304/316 | #304/316 | #304/316 | #304/316 |
| Lamp power | 110W | 165W | 220W | 330W | 440W | 550W | 660W |
| Input voltage | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz | 110V/240V 50/60Hz |
| UV lamp quantity | 2 | 3 | 4 | 6 | 8 | 10 | 12 |
| Water treatment capability | 24GPM (5.5m³/Hr) | 36GPM (8m³/Hr) | 48GPM (11m³/Hr) | 72GPM (16m³/Hr) | 96GPM (22m³/Hr) | 120GPM (30m³/Hr) | 144GPM (35m³/Hr) |
| Water capacity | 8130cm³ | 12330cm³ | 12330cm³ | 19674cm³ | 33739cm³ | 33739cm³ | 33739cm³ |
| Max operating pressure | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) | 10bar(145psi) |
| Test pressure | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) | 15bar(218psi) |
Application
1. Seawater and freshwater breeding (fish, clams, shrimps, shellfish, etc.) are disinfected with water.
2, food processing industry water disinfection, including juice, milk, beverages, beer, cooking oil and all kinds of cans, cold drinks and other water equipment.
3, hospitals, various types of laboratory water disinfection and high levels of pathogenic body water disinfection.
4. Domestic water disinfection, including residential quarters, office buildings, waterworks, hotel restaurants, etc.
5, biochemical pharmaceutical, cosmetic production with cooling water disinfection.
6. Water disinfection of swimming pools and water recreation facilities.
